Single cabinet CR4000-LC series

CR4000-LC series liquid cooled cloud cabinet is a new generation of data center cabinet, liquid cooled cabinet has the characteristics of high efficiency, energy saving and environmental protection. Compared with the traditional air-cooled cooling method, the liquid-cooled cabinet has higher cooling efficiency and lower energy consumption. The core components of the CR4000-LC series of liquid cooled cloud cabinets include components such as cold plates, pumps and heat exchangers. The cold plates interact with the heat source and equipment to remove heat from the equipment through liquid circulation. The pump circulates the liquid through the system, ensuring constant heat transfer. Heat exchangers discharge the heat absorbed by the liquid to the external environment to keep the temperature of the system stable, so the liquid-cooled cabinet is the best choice for the new generation of data centers.

  • Efficient cooling

    Liquid cooling systems have high heat conductivity and can achieve efficient heat transfer in a small space, thereby improving the cooling efficiency of the data center.

  • Improve performance

    Due to increased cooling efficiency, equipment in data centers can operate at lower temperatures, thereby improving their performance and stability.


  • Life extension

    The liquid-cooled cabinet can effectively reduce the temperature of the device and reduce the risk of device damage due to overheating, thus extending the service life of the device.

  • Energy saving and environmental protection

    Compared with the traditional air-cooled cooling method, the liquid-cooled cabinet does not use a lot of electricity to drive the fan, so it has lower energy consumption and less carbon emissions.

Application scenario

  • Headquarters

  • Large Branch

  • Bank

  • Government

  • Operator

  • Education

  • Medical

  • Power
It is mainly used in large and medium-sized enterprise core computer rooms, smart cities and core data centers, large operator data centers, IDC large and medium-sized data centers, and large super data centers. Data center deployment needs of enterprise headquarters or large branches, bank head offices and secondary branches, government, operators, education, healthcare, power and other industries.
    Technical specification

    Name Specifications
    Centralized management Single cabinet power environment monitoring and server monitoring
    Display 13.3-inch touch screen (1400mm optional)
    Maximum power supply 3*39.6kW (no redundancy), 3x36kW(3 redundant modules)
    Power module efficiency 96%
    Rack CDU cooling capacity 100kW
    Inlet water temperature 20℃~45℃
    System cooling Cold plate liquid cooling + backplane evaporative cooling (optional)
    Cabinet dimensions: W x D x H (mm) 600*1200/1400*2200
    Cabinet bearing > 3100kg
    Input voltage AC380/DC240V
    Input routes Two AC or one AC+ one DC
    Input AC voltage range 180 Vac to 264 Vac
    Input frequency range 45Hz to 65Hz
    Input DC voltage range 180Vdc to 320Vdc
    Output rated voltage DC54V
    Operating temperature 5℃~40℃
    Working humidity 8% ~ 90%
    Working altitude ≤ 3050m
